Auxiliary Relay (Timer Contactor) LADR4/10-180sec
-
Estimated Delivery:Apr 26 - Apr 30
-
Free Delivery: Any order over 300 lei
Auxiliary Relay (Timer Contactor) LADR4/10-180sec
Auxiliary Relay (Timer Contactor) LADR4/10-180sec
Auxiliary Relay (Timer Contactor) easy to use, having a wide range of work:
billboards, road lamps, street milk, mechanical equipment, electrical panels, etc.
The accuracy and reliability of this device recommend it to be used in multiple programming uses
for lighting and controlled electrical systems.
Technical details:
Electricity type: AC
Rated main circuit voltage: 600v
Product Name: Latching Time Relay
Model: LADR4
Material: Plastic, Electrical parts
Main color: Black, White
Contact: 1NO + 1NC
Rated insulation voltage (Ui): 660V
Conventional thermal current (I): 10A
Delay range: 10 - 180s
Overall size: 4.5 x 5 x 6 cm / 1.8" x 2" x 2.4" (L * W * T)
Careful!
1. The device and its accessories must be installed in accordance with the purpose for which they were designed.
2. Installation and commissioning must be carried out by a person authorized in this regard.
3. In case of operational problems, please contact a competent person in this regard.
4. Otherwise, an unprofessional intervention may damage the product and automatically void its warranty.
Package Contents:
1 x Auxiliary Relay (Timer Contactor) LADR4/10-180sec
